24AA65T/SM - Microchip
Ic, serial Eeprom, 8Kx8, cmos, sop, 8Pin, plastic Rohs Compliant: Yes |Microchip 24AA65T/SM
Technical Details
| Projected EOL Date | 2034-05-16 |
| Access Time | 3.5µs |
| Case/Package | SOIC |
| Country of Assembly | Thailand |
| Country of Fabrication | United States of America |
| Country of Origin | Thailand |
| Density | 64kb |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Frequency | 400kHz |
| Harmonized Tariff Schedule (HTS) Code | 8542.32.0051 |
| Interface | I2C, Serial |
| Introduction Date | 2002-05-16 |
| Lead Free | Lead Free |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | REL |
| Max Frequency | 100kHz |
| Max Operating Temperature | 70°C |
| Max Supply Voltage | 6V |
| Memory Type | EEPROM |
| Min Operating Temperature | 0°C |
| Min Supply Voltage | 1.8V |
| Mount | Surface Mount |
| Nominal Supply Current | 3mA |
| Number of Pins | 8 |
| Packaging | Tape & Reel (TR) |
| Radiation Hardening | No |
| RoHS | Compliant |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
Images
Onlinecomponents.com
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Microchip | Production | ||
| Microchip | Production | ||
| Samsung | Unknown | ||
| Catalyst Semiconductor | Obsolete | ||
| Microchip | Unknown | ||
| Catalyst Semiconductor | Obsolete | ||
| Microchip | Production | ||
| Microchip | Unknown | ||
| Microchip | Production | ||
| Catalyst Semiconductor | Obsolete |
