24LC04BT-I/MNY - Microchip
EEPROM Serial-I2C 4K-bit 2Block x 256 x 8 3.3V/5V 8-Pin TDFN EP T/R
Technical Details
| Projected EOL Date | 2034-11-25 |
| Access Time | 900ns |
| Contact Plating | Gold |
| Country of Assembly | Thailand |
| Country of Fabrication | United States of America |
| Country of Origin | Thailand |
| Density | 4kb |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Frequency | 400kHz |
| Harmonized Tariff Schedule (HTS) Code | 8542.32.0051 |
| Interface | I2C, Serial |
| Introduction Date | 2008-11-25 |
| Lead Free | Lead Free |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | REL |
| Max Frequency | 400kHz |
| Max Operating Temperature | 85°C |
| Max Supply Voltage | 5.5V |
| Memory Size | 512B |
| Memory Type | EEPROM |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.5V |
| Mount | Surface Mount |
| Nominal Supply Current | 3mA |
| Number of Pins | 8 |
| Operating Supply Voltage | 5V |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| RoHS | Compliant |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
Images
Microchip
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Microchip | Unknown | ||
| Microchip | Unknown | ||
| Microchip | Production | ||
| Microchip | Production | ||
| Microchip | Unknown | ||
| Atmel | Unknown | ||
| STMicroelectronics | Obsolete | ||
| Microchip | Unknown | ||
| Microchip | Production | ||
| Microchip | Production |
