24LC21A/P - Microchip
Ic, serial Eeprom, 128X8, cmos, dip, 8Pin, plastic Rohs Compliant: Yes |Microchip 24LC21A/P
Technical Details
| Projected EOL Date | 2034-05-16 |
| Access Time | 900ns |
| Case/Package | PDIP |
| Country of Assembly | Thailand |
| Country of Fabrication | United States of America |
| Country of Origin | Thailand |
| Density | 1kb |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Frequency | 400kHz |
| Height | 4.953mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.32.0051 |
| Interface | I2C, Serial |
| Introduction Date | 2002-01-01 |
| Lead Free | Lead Free |
| Length | 10.16mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | REL |
| Max Frequency | 400kHz |
| Max Operating Temperature | 70°C |
| Max Supply Voltage | 5.5V |
| Memory Type | EEPROM |
| Min Operating Temperature | 0°C |
| Min Supply Voltage | 2.5V |
| Mount | Through Hole |
| Nominal Supply Current | 3mA |
| Number of Pins | 8 |
| Number of Words | 128 |
| Packaging | Bulk |
| Radiation Hardening | No |
| RoHS | Compliant |
| Width | 7.112mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
Images
Microchip
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Microchip | Production | ||
| Microchip | Unknown | ||
| Microchip | Production | ||
| Microchip | Production | ||
| Microchip | Production | ||
| Microchip | Production | ||
| STMicroelectronics | Obsolete | ||
| Microchip | Production | ||
| Microchip | Unknown | ||
| Microchip | Unknown |
