25LC080/SN - Microchip
Microchip 25LC080/SN Serial EEPROM Memory; 8kbit; 230ns; 2.5 to 5.5 V 8-Pin SOIC
Technical Details
| Projected EOL Date | 2034-05-16 |
| Access Time | 230ns |
| Case/Package | SOIC |
| Country of Assembly | Thailand |
| Country of Fabrication | United States of America |
| Country of Origin | Thailand |
| Density | 8kb |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Frequency | 2MHz |
| Height | 1.25mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.32.0051 |
| Interface | SPI, Serial |
| Introduction Date | 2002-01-01 |
| Lead Free | Lead Free |
| Length | 4.9mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | REL |
| Max Frequency | 2MHz |
| Max Operating Temperature | 70°C |
| Max Supply Voltage | 5.5V |
| Memory Size | 1kB |
| Memory Type | EEPROM |
| Min Operating Temperature | 0°C |
| Min Supply Voltage | 2.5V |
| Nominal Supply Current | 5mA |
| Number of Pins | 8 |
| Operating Supply Voltage | 2.5V |
| Packaging | Bulk |
| Radiation Hardening | No |
| REACH SVHC | No |
| RoHS | Compliant |
| Schedule B | 8542320050, 8542320050|8542320050|8542320050|8542320050|8542320050 |
| Width | 3.9mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
