2N2905A - Microchip
TRANS PNP 60V 0.6A TO39 Bipolar (BJT) Transistor PNP 60 V 600 mA 800 mW Through Hole TO-39 (TO-205AD)
Technical Details
| Projected EOL Date | 2049-02-05 |
| Case/Package | TO-39 |
| Collector Base Voltage (VCBO) | 60V |
| Collector Emitter Breakdown Voltage | 60V |
| Collector Emitter Saturation Voltage | 1.6V |
| Collector Emitter Voltage (VCEO) | 60V |
| Country of Assembly | Philippines |
| Country of Fabrication | United States of America |
| Country of Origin | PHL |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Emitter Base Voltage (VEBO) | 5V |
| Height | 6.6mm |
| hFE Min | 100 |
| Harmonized Tariff Schedule (HTS) Code | 8541.21.0095 |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | REL |
| Max Collector Current | 600mA |
| Max Junction Temperature (Tj) | 200°C |
| Max Operating Temperature | 200°C |
| Max Power Dissipation | 800mW |
| Min Operating Temperature | -65°C |
| Mount | Through Hole |
| Number of Elements | 1 |
| Packaging | Bulk |
| Polarity | PNP |
| Power Dissipation | 800mW |
| Radiation Hardening | No |
| RoHS | Compliant |
| Schedule B | 8541210080, 8541210080|8541210080, 8541210080|8541210080|8541210080, 8541210080|8541210080|8541210080|8541210080 |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
Images
Master Electronics
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| onsemi | Obsolete | ||
| STMicroelectronics | Obsolete | ||
| onsemi | Obsolete | ||
| onsemi | Obsolete | ||
| Semicoa | Unknown | ||
| Texas Instruments | Unknown | ||
| Motorola | Obsolete | ||
| Motorola | Obsolete | ||
| NXP Semiconductors | Obsolete | ||
| CDIL | Unknown |
