AT86RF232-ZXR - Microchip
2.4GHZ Zigbee Transceiver Commercial T&r 32 VQFN 5X5X0.9MM T/r Rohs Compliant: Yes
Technical Details
| Projected EOL Date | 2039-06-13 |
| Country of Assembly | Philippines |
| Country of Fabrication | N/A |
| Country of Origin | Philippines |
| Current - Receiving | 11.8mA |
| Current - Transmitting | 13.8mA |
| Data Rate | 250kbps |
| Export Control Classification Number (ECCN) Code | 5A992.c |
| Frequency | 2.4GHz |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.0010 |
| Interface | SPI |
| Lead Free | Lead Free |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | REL |
| Max Frequency | 2.48GHz |
| Max Operating Temperature | 70°C |
| Max Supply Current | 13.8mA |
| Max Supply Voltage | 3.6V |
| Memory Size | 128B |
| Min Operating Temperature | 0°C |
| Min Supply Voltage | 1.8V |
| Mount | Surface Mount |
| Number of Pins | 32 |
| Number of Receivers | 1 |
| Number of Timers/Counters | 0 |
| Number of Transmitters | 1 |
| Number of UART Channels | 0 |
| Radiation Hardening | No |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Sensitivity (dBm) | -100dBm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
