AT86RF233-ZF - Microchip
High Performance RF-CMOS 2.4GHz radio transceiver targeted for IEEE® 802.15.4,
Technical Details
| Projected EOL Date | 2039-10-30 |
| Case/Package | VQFN |
| Country of Assembly | Philippines, Thailand |
| Country of Fabrication | Taiwan |
| Country of Origin | Philippines, Thailand |
| Current - Receiving | 11.8mA |
| Current - Transmitting | 13.8mA |
| Data Rate | 2Mbps |
| Export Control Classification Number (ECCN) Code | 5A992.c |
| Frequency | 2.4GHz |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.0010 |
| Interface | SPI |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | REL |
| Max Frequency | 2.527GHz |
| Max Operating Temperature | 125°C |
| Max Supply Voltage | 3.6V |
| Memory Size | 128B |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 1.8V |
| Number of Channels | 16 |
| Number of Pins | 32 |
| Operating Supply Voltage | 3V |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Sensitivity (dBm) | -101dBm |
