ATTINY261A-XUR - Microchip
ATtiny Series 2 KB Flash 128 B SRAM 20 MHz 8-Bit Microcontroller - TSSOP-20
Technical Details
| Projected EOL Date | 2039-03-14 |
| Contact Plating | Tin |
| Core Architecture | AVR |
| Country of Assembly | Taiwan |
| Country of Fabrication | United States of America |
| Country of Origin | Taiwan |
| Data Bus Width | 8b |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Frequency | 20MHz |
| Harmonized Tariff Schedule (HTS) Code | 8542.31.0015 |
| Interface | SPI |
| Lead Free | Lead Free |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | REL |
| Max Frequency | 20MHz |
| Max Operating Temperature | 85°C |
| Max Supply Voltage | 5.5V |
| Memory Size | 2kB |
| Memory Type | FLASH |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 1.8V |
| Mount | Surface Mount |
| Number of I/Os | 16 |
| Number of Pins | 20 |
| Number of Programmable I/O | 16 |
| Number of Timers/Counters | 2 |
| Oscillator Type | Internal |
| Peripherals | Brown-out Detect/Reset, POR, PWM, Temp Sensor, WDT |
| RAM Size | 128B |
| RoHS | Compliant |
| Watchdog Timer | Yes |
Compliance
RoHS : Unconfirmed
