ATWINC1500-MR210PB1954 - Microchip
RF TXRX MOD WIFI TRACE ANT SMD "WiFi 802.11b/g/n Transceiver Module 2.4GHz Integrated, Trace Surface Mount"
Technical Details
| Projected EOL Date | 2044-11-08 |
| Bandwidth | 20MHz |
| Case/Package | Module |
| Country of Assembly | Taiwan, Thailand |
| Country of Fabrication | N/A |
| Country of Origin | Taiwan, Thailand |
| Current - Receiving | 83mA |
| Current - Transmitting | 287mA |
| Data Rate | 72.2Mbps |
| Export Control Classification Number (ECCN) Code | 5A992.c |
| Height | 2.113mm |
| Harmonized Tariff Schedule (HTS) Code | 8529.90.2100 |
| Interface | I2C, SPI, UART |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | REL |
| Max Frequency | 2.472GHz |
| Max Operating Temperature | 85°C |
| Max Supply Voltage | 4.2V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.7V |
| Number of Pins | 28 |
| RoHS | Compliant |
Compliance
RoHS : Unconfirmed
