IS1871SF-102-TRAY - Microchip
Bluetooth BLE5 IC, 4X4MM, Industrial Temp 32 VQFN 4X4X0.9MM Tray Rohs Compliant: Yes
Technical Details
| Projected EOL Date | 2039-08-04 |
| Bandwidth | 78MHz |
| Case/Package | VQFN |
| Country of Assembly | Taiwan, Thailand |
| Country of Fabrication | Taiwan |
| Country of Origin | Taiwan, Thailand |
| Current - Receiving | 10mA |
| Current - Transmitting | 10mA |
| Data Rate | 921.6kbps |
| Export Control Classification Number (ECCN) Code | 5A992.c |
| Height | 900µm |
| Harmonized Tariff Schedule (HTS) Code | 8542.31.0070 |
| Interface | I2C, SPI, UART |
| Introduction Date | 2015-08-04 |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | REL |
| Max Frequency | 2.48GHz |
| Max Operating Temperature | 85°C |
| Max Supply Voltage | 3.6V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 1.9V |
| Number of ADC Channels | 6 |
| Number of GPIO | 15 |
| Number of Pins | 32 |
| RoHS | Compliant |
Compliance
RoHS : Unconfirmed
