Microchip MCP102T-195I/TT; Voltage Supervisor 1.853 to 1.948 V; 3-Pin SOT-23B
Technical Details
| Projected EOL Date | 2034-10-01 |
| Country of Assembly | Thailand |
| Country of Fabrication | United States of America |
| Country of Origin | Thailand |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 1.02mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.0060 |
| Introduction Date | 2004-10-01 |
| Lead Free | Lead Free |
| Length | 3.04mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | REL |
| Max Operating Temperature | 85°C |
| Max Reset Threshold Voltage | 1.929V |
| Max Supply Current | 1.75µA |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -40°C |
| Min Reset Threshold Voltage | 1.872V |
| Min Supply Voltage | 1V |
| Mount | Surface Mount |
| Number of Pins | 3 |
| Number of Voltages Monitored | 1 |
| Operating Supply Current | 1.75µA |
| Overvoltage Threshold | 1.929V |
| Packaging | Cut Tape |
| Quiescent Current | 1µA |
| Radiation Hardening | No |
| REACH SVHC | No |
| Reset | Active Low |
| Reset Timeout | 80ms |
| RoHS | Compliant |
| Threshold Voltage | 1.9V |
| Type | Simple Reset/Power-On Reset |
| Undervoltage Threshold | 1.872V |
| Watchdog Timer | No |
| Width | 1.4mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
