MCP112T-300E/LB - Microchip
Microchip MCP112T-300E/LB, Voltage Supervisor 2.857 to 3.003 V, 3-PIN SC-70
Technical Details
| Projected EOL Date | 2034-06-08 |
| Case/Package | SC |
| Country of Assembly | Thailand |
| Country of Fabrication | United States of America |
| Country of Origin | Thailand |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 1mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.0060 |
| Introduction Date | 2004-06-08 |
| Lead Free | Lead Free |
| Length | 2.25mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | REL |
| Max Operating Temperature | 125°C |
| Max Output Current | 10mA |
| Max Reset Threshold Voltage | 2.974V |
| Max Supply Current | 1.75µA |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -40°C |
| Min Reset Threshold Voltage | 2.886V |
| Min Supply Voltage | 1V |
| Mount | Surface Mount |
| Nominal Supply Current | 1µA |
| Number of Pins | 3 |
| Number of Voltages Monitored | 1 |
| Operating Supply Current | 1.75µA |
| Output Type | Voltage |
| Overvoltage Threshold | 2.974V |
| Packaging | Tape & Reel (TR) |
| Quiescent Current | 1µA |
| Radiation Hardening | No |
| REACH SVHC | No |
| Reset | Active Low |
| RoHS | Compliant |
| Threshold Voltage | 2.93V |
| Type | Simple Reset/Power-On Reset, Voltage Detector |
| Undervoltage Threshold | 2.886V |
| Watchdog Timer | No |
| Width | 1.35mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
