MCP1321T-29ME/OT - Microchip
IC SUPERVISOR 1 CHANNEL SOT23-5 "Supervisor Open Drain, Push-Pull 1 Channel SOT-23-5"
Technical Details
| Projected EOL Date | 2034-11-12 |
| Country of Assembly | Malaysia, Thailand |
| Country of Fabrication | United States of America |
| Country of Origin | Malaysia, Thailand |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.0060 |
| Introduction Date | 2008-11-12 |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | REL |
| Max Operating Temperature | 125°C |
| Max Power Dissipation | 240mW |
| Max Reset Threshold Voltage | 2.944V |
| Max Supply Current | 10µA |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -40°C |
| Min Reset Threshold Voltage | 2.857V |
| Min Supply Voltage | 1V |
| Mount | Surface Mount |
| Nominal Supply Current | 10µA |
| Number of Elements | 1 |
| Number of Pins | 5 |
| Number of Voltages Monitored | 1 |
| Operating Supply Current | 10µA |
| Overvoltage Threshold | 2.944V |
| Power Dissipation | 240mW |
| Quiescent Current | 1µA |
| Radiation Hardening | No |
| Reset | Active High/Active Low |
| Reset Timeout | 140ms |
| RoHS | Compliant |
| Threshold Voltage | 2.9V |
| Type | Simple Reset/Power-On Reset |
| Undervoltage Threshold | 2.857V |
| Watchdog Timer | Yes |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
