Microchip - MCP14E4-E/MF

MCP14E4-E/MF - Microchip

IC GATE DRVR LOW-SIDE 8DFN Low-Side Gate Driver IC Non-Inverting 8-DFN-S (6x5)

 Datasheets

Technical Details

Projected EOL Date 2034-09-28
Case/Package DFN
Country of Assembly Philippines, Thailand
Country of Fabrication United States of America
Country of Origin Philippines, Thailand
Export Control Classification Number (ECCN) Code EAR99
Fall Time 30ns
Harmonized Tariff Schedule (HTS) Code 8542.33.0001
Introduction Date 2007-09-28
Lead Free Lead Free
Lifecycle Status Production
Manufacturer Lifecycle Status REL
Max Operating Temperature 125°C
Max Output Current 4A
Max Supply Current 2mA
Max Supply Voltage 18V
Min Operating Temperature -40°C
Min Supply Voltage 4.5V
Mount Surface Mount
Nominal Supply Current 2mA
Number of Drivers 2
Number of Outputs 2
Number of Pins 8
Propagation Delay 60ns
Radiation Hardening No
Rise Time 30ns
RoHS Compliant
Turn-On Delay Time 60ns
