MCP1700T-2502E/TT - Microchip
LDO Regulator Pos 2.5V 0.25A Automotive 3-Pin SOT-23 T/R / IC REG LDO 2.5V 0.25A SOT23-3
Technical Details
| Projected EOL Date | 2034-08-12 |
| Accuracy | 2% |
| Case/Package | SOT-23 |
| Country of Assembly | Thailand |
| Country of Fabrication | United States of America |
| Country of Origin | Thailand |
| Dropout Voltage | 178mV |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 950µm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.0060 |
| Input Bias Current | 1.6µA |
| Introduction Date | 2003-08-12 |
| Lead Free | Lead Free |
| Length | 2.9mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | REL |
| Max Input Voltage | 6V |
| Max Operating Temperature | 125°C |
| Max Output Current | 250mA |
| Max Power Dissipation | 369.6mW |
| Min Input Voltage | 2.3V |
| Min Operating Temperature | -40°C |
| Min Output Voltage | 2.5V |
| Mount | Surface Mount |
| Nominal Output Voltage | 2.5V |
| Nominal Supply Current | 4µA |
| Number of Channels | 1 |
| Number of Outputs | 1 |
| Number of Pins | 3 |
| Output Current | 250mA |
| Output Type | Fixed |
| Output Voltage | 2.5V |
| Output Voltage Accuracy | 2% |
| Packaging | Cut Tape |
| Polarity | Positive |
| Quiescent Current | 4µA |
| Radiation Hardening | No |
| REACH SVHC | No |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Width | 1.3mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
Images
TME
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| STMicroelectronics | Production | ||
| Microchip | Production | ||
| Microchip | Production | ||
| Microchip | Production | ||
| Microchip | Production | ||
| Microchip | Production | ||
| Diodes Inc. | Obsolete | ||
| Torex | NRND | ||
| Taiwan Semiconductor | Production | ||
| Toko | Obsolete |
