Technical Details
| Projected EOL Date | 2034-04-14 |
| Accuracy | 2% |
| Country of Assembly | Thailand |
| Country of Fabrication | United States of America |
| Country of Origin | Thailand |
| Dropout Voltage | 178mV |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.0060 |
| Introduction Date | 2004-04-14 |
| Lead Free | Lead Free |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | REL |
| Max Input Voltage | 6.5V |
| Max Operating Temperature | 125°C |
| Min Input Voltage | 2.3V |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Outputs | 1 |
| Number of Pins | 3 |
| Output Current | 250mA |
| Output Type | Fixed |
| Output Voltage | 2.7V |
| Polarity | Positive |
| Quiescent Current | 4µA |
| Radiation Hardening | No |
| RoHS | Compliant |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
Images
