MCP1727T-ADJE/SN - Microchip
LDO Regulator Pos 0.8V to 5V 1.5A Automotive 8-Pin SOIC N T/R
Technical Details
| Projected EOL Date | 2034-08-02 |
| Accuracy | 0.5% |
| Case/Package | SOIC |
| Country of Assembly | China, Thailand |
| Country of Fabrication | United States of America |
| Country of Origin | China, Thailand |
| Dropout Voltage | 330mV |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.0060 |
| Input Bias Current | 120µA |
| Introduction Date | 2006-08-02 |
| Lead Free | Lead Free |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | REL |
| Max Input Voltage | 6V |
| Max Operating Temperature | 125°C |
| Min Input Voltage | 2.3V |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Outputs | 1 |
| Number of Pins | 8 |
| Output Current | 1.5A |
| Output Type | Adjustable |
| Output Voltage | 5V |
| Packaging | Tape & Reel (TR) |
| Polarity | Positive |
| Quiescent Current | 220µA |
| Radiation Hardening | No |
| Reference Voltage | 410mV |
| RoHS | Compliant |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
