Technical Details
| Projected EOL Date | 2034-07-27 |
| Accuracy | 2% |
| Country of Origin | Japan |
| Dropout Voltage | 1.3V |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.0060 |
| Introduction Date | 2009-07-27 |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | REL |
| Max Input Voltage | 28V |
| Max Operating Temperature | 85°C |
| Max Power Dissipation | 500mW |
| Min Input Voltage | 2V |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Outputs | 1 |
| Number of Pins | 5 |
| Output Current | 150mA |
| Output Type | Fixed |
| Output Voltage | 3V |
| Packaging | Tape & Reel |
| Polarity | Positive |
| Quiescent Current | 105µA |
| Radiation Hardening | No |
| RoHS | Compliant |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
