MIC2287CYD5-TR - Microchip
MIC2287 Series 500 mA 10 V 1.2 MHz Surface Mount PWM White LED Driver - SOT-23-5
Technical Details
| Projected EOL Date | 2034-05-27 |
| Country of Assembly | Malaysia |
| Country of Fabrication | United States of America |
| Country of Origin | Malaysia |
| Dimming | Analog, PWM |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Frequency | 1.2MHz |
| Height | 1mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.0060 |
| Lead Free | Lead Free |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | REL |
| Max Input Voltage | 10V |
| Max Junction Temperature (Tj) | 105°C |
| Max Operating Temperature | 105°C |
| Max Supply Current | 5mA |
| Max Supply Voltage | 10V |
| Min Input Voltage | 2.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.5V |
| Mount | Surface Mount |
| Nominal Supply Current | 2.5mA |
| Number of Outputs | 1 |
| Number of Pins | 5 |
| Number of Segments | 6 |
| Output Current | 500mA |
| Output Current per Channel | 750mA |
| Output Voltage | 37V |
| Packaging | Cut Tape |
| REACH SVHC | No |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Switching Frequency | 1.2MHz |
| Termination | SMD/SMT |
| Topology | Boost |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
