MIC2297-42YML-TR - Microchip
Tape & Reel (TR) MIC2297 Step-Up (Boost) PWM led driver 1.2A Switch 10V 600kHz -40C~125C TJ
Technical Details
| Projected EOL Date | 2025-10-18 |
| Country of Assembly | Malaysia |
| Country of Fabrication | United States of America |
| Country of Origin | Malaysia |
| Dimming | PWM |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Frequency | 600kHz |
| Height | 900µm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.0060 |
| Lead Free | Lead Free |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | PHAS |
| Max Input Voltage | 10V |
| Max Junction Temperature (Tj) | 125°C |
| Max Operating Temperature | 125°C |
| Max Supply Voltage | 10V |
| Min Input Voltage | 2.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 1.8V |
| Mount | Surface Mount |
| Nominal Supply Current | 4mA |
| Number of Channels | 1 |
| Number of Outputs | 1 |
| Number of Pins | 10 |
| Number of Segments | 10 |
| Output Current | 1.2A |
| Output Current per Channel | 1.2A |
| Output Voltage | 40V |
| Packaging | Cut Tape |
| Radiation Hardening | No |
| REACH SVHC | No |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000, 8542390000|8542390000|8542390000, 8542390000|8542390000|8542390000|8542390000 |
| Switching Frequency | 600kHz |
| Termination | SMD/SMT |
| Topology | Boost |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
