MIC29152WU - Microchip
MIC29152 Series 1.5 A 1.25 to 25 V ADJ Output LDO Voltage Regulator - TO-263-5
Technical Details
| Projected EOL Date | 2034-02-11 |
| Accuracy | 1% |
| Case/Package | TO-263 |
| Country of Assembly | China |
| Country of Fabrication | United States of America |
| Country of Origin | China |
| Current Rating | 1.5A |
| Dropout Voltage | 350mV |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 4.59mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.0060 |
| Input Bias Current | 40nA |
| Lead Free | Lead Free |
| Length | 10.67mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | REL |
| Max Input Voltage | 26V |
| Max Operating Temperature | 125°C |
| Max Output Current | 1.5A |
| Max Output Voltage | 25V |
| Min Input Voltage | 2.5V |
| Min Operating Temperature | -40°C |
| Min Output Voltage | 1.27V |
| Mount | Surface Mount |
| Number of Channels | 1 |
| Number of Outputs | 1 |
| Number of Pins | 5 |
| Number of Regulators | 1 |
| Output Current | 1.5A |
| Output Type | Adjustable |
| Output Voltage | 26V |
| Output Voltage Accuracy | 1% |
| Packaging | Bulk |
| Polarity | Positive |
| Quiescent Current | 20mA |
| Radiation Hardening | No |
| REACH SVHC | No |
| Reference Voltage | 1.24V |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Width | 9.17mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
Images
Farnell
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Micrel | Unknown | ||
| Microchip | Production | ||
| Taiwan Semiconductor | Obsolete | ||
| Taiwan Semiconductor | Obsolete | ||
| Microchip | Production | ||
| Microchip | Production | ||
| Micrel | Unknown | ||
| HTC Korea | Unknown | ||
| HTC Korea | Unknown | ||
| HTC Korea | Unknown |
