Technical Details
| Projected EOL Date | 2034-09-07 |
| Case/Package | TQFP |
| Core Architecture | PIC |
| Country of Assembly | Philippines, Thailand |
| Country of Fabrication | United States of America |
| Country of Origin | Philippines, Thailand |
| Data Bus Width | 8b |
| Density | 768kb |
| Export Control Classification Number (ECCN) Code | 3A991.a.2 |
| Frequency | 40MHz |
| Height | 1.05mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.31.0015 |
| Interface | I2C, SPI, UART, USART |
| Introduction Date | 2007-09-07 |
| Lead Free | Lead Free |
| Length | 10mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | REL |
| Max Frequency | 40MHz |
| Max Operating Temperature | 85°C |
| Max Power Dissipation | 1W |
| Max Supply Voltage | 5.5V |
| Memory Size | 96kB |
| Memory Type | FLASH |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2V |
| Mount | Surface Mount |
| Number of A/D Converters | 1 |
| Number of ADC Channels | 12 |
| Number of Bits | 8 |
| Number of I2C Channels | 2 |
| Number of I/Os | 54 |
| Number of Pins | 64 |
| Number of Programmable I/O | 54 |
| Number of PWM Channels | 14 |
| Number of SPI Channels | 2 |
| Number of Timers/Counters | 5 |
| Number of UART Channels | 2 |
| Operating Supply Voltage | 3.3V |
| Oscillator Type | Internal |
| Peripherals | Brown-out Detect/Reset, HLVD, POR, PWM, WDT |
| Radiation Hardening | No |
| RAM Size | 3.8kB |
| REACH SVHC | No |
| RoHS | Compliant |
| Width | 10mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
Images
Microchip
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Microchip | Production | ||
| Microchip | Production | ||
| Microchip | Unknown | ||
| Microchip | Unknown | ||
| Microchip | Production | ||
| Microchip | Unknown | ||
| Microchip | Production | ||
| Microchip | Production | ||
| Microchip | Production | ||
| Microchip | Unknown |
