TC4452VPA - Microchip
IC GATE DRVR LOW-SIDE 8DIP Low-Side Gate Driver IC Non-Inverting 8-PDIP
Technical Details
| Projected EOL Date | 2034-02-06 |
| Case/Package | PDIP |
| Country of Assembly | Thailand |
| Country of Fabrication | United States of America |
| Country of Origin | Thailand |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Fall Time | 40ns |
| Height | 4.95mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.0060 |
| Introduction Date | 2006-02-06 |
| Lead Free | Lead Free |
| Length | 10.16mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | REL |
| Max Operating Temperature | 125°C |
| Max Output Current | 13A |
| Max Supply Current | 200µA |
| Max Supply Voltage | 18V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 4.5V |
| Mount | Through Hole |
| Nominal Supply Current | 200µA |
| Number of Channels | 1 |
| Number of Drivers | 1 |
| Number of Pins | 8 |
| Output Voltage | 18V |
| Propagation Delay | 52ns |
| Radiation Hardening | No |
| REACH SVHC | No |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000, 8542390000|8542390000|8542390000, 8542390000|8542390000|8542390000|8542390000 |
| Turn-On Delay Time | 52ns |
| Width | 7.11mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
Images
TME
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Elantec | Obsolete | ||
| Texas Instruments | Unknown | ||
| IXYS | Obsolete | ||
| Texas Instruments | Unknown | ||
| Analog Devices | Unknown | ||
| Analog Devices | Unknown | ||
| onsemi | Obsolete | ||
| Microchip | Unknown | ||
| Microchip | Production | ||
| Analog Devices | Unknown |
