Technical Details
| Access Time | 700ps |
| Case/Package | TSSOP |
| China RoHS | Compliant |
| Density | 512Mb |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Frequency | 200MHz |
| Height - Seated (Max) | 1.2mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.32.00.28 |
| Introduction Date | 1999-02-01 |
| Lead Free | Lead Free |
| Length | 22.22mm |
| Lifecycle Status | Production |
| Max Frequency | 200MHz |
| Max Operating Temperature | 70°C |
| Max Supply Current | 185mA |
| Max Supply Voltage | 2.7V |
| Min Operating Temperature | 0°C |
| Min Supply Voltage | 2.5V |
| Number of Circuits | 1 |
| Number of Pins | 66 |
| Number of Ports | 1 |
| Number of Terminals | 66 |
| Operating Supply Voltage | 2.6V |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Temperature Grade | Commercial |
| Terminal Pitch | 650µm |
| Voltage | 2.6V |
| Voltage Rating (DC) | 2.6V |
| Width | 10.16mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
