RCBT-63+ - Mini-Circuits
Monitor TEE DC Block, 10MHz Min, 6000MHz Max, 2dB Insertion Loss-Max
Technical Details
| Bandwidth | 5.99GHz |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 4.06mm |
| Impedance | 50Ω |
| Insertion Loss (dB) | 2dB |
| Introduction Date | 2018-08-08 |
| Lifecycle Status | Production |
| Max Frequency | 6GHz |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Terminals | 6 |
| RoHS | Compliant |
| Voltage Rating (DC) | 25V |
Compliance
RoHS : Unconfirmed
