Technical Details
| China RoHS | Compliant |
| Color | Black, Yellow |
| Connector Type | Power, Receptacle, Rectangular, Socket |
| Contact Gender | Female |
| Contact Plating | Tin |
| Country of Origin | US |
| Current Rating | 30A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Fastening Type | Latch |
| Flammability Rating | UL94 V-0 |
| Gender | Receptacle |
| Glow Wire Compliant | Non-compliant |
| Housing Material | PBT |
| Harmonized Tariff Schedule (HTS) Code | 8536.69.40.30 |
| Insulation Resistance | 1GΩ |
| Introduction Date | 2009-11-04 |
| Length | 27.07mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Operating Temperature | 125°C |
| Max Voltage Rating (AC) | 600V |
| Min Operating Temperature | -40°C |
| Mount | Cable, Free Hanging |
| Number of Contacts | 4 |
| Number of Pins | 4 |
| Number of Positions | 4 |
| Number of Rows | 2 |
| Orientation | Straight |
| Packaging | Bulk |
| Pitch | 7.62mm |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Row Spacing | 9.8044mm |
| Termination | Crimp |
| Voltage Rating | 600V |
| Voltage Rating (AC) | 600V |
| Voltage Rating (DC) | 600V |
| Wire/Cable Gauge | 12AWG |
| Wire Gauge (Max) | 12AWG |
| Wire Gauge (Min) | 10AWG |
| Working Voltage | 600V |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
