30700-1209 - Molex
Combination Line Connector, 20 Contact(s), Female, Crimp Terminal, Receptacle
Technical Details
| China RoHS | Compliant |
| Color | Natural |
| Connector Type | Receptacle, Socket |
| Contact Gender | Female |
| Country of Origin | US |
| Current Rating | 7A |
| Depth | 24.22mm |
| Dielectric Material | Polyester |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Fastening Type | Latch |
| Gender | Receptacle |
| Housing Color | Natural |
| Housing Material | Steel |
| Harmonized Tariff Schedule (HTS) Code | 8536.69.40.30 |
| Introduction Date | 2005-05-26 |
| Length | 30.69mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Operating Temperature | 100°C |
| Max Voltage Rating (DC) | 500V |
| Min Operating Temperature | -40°C |
| Mount | Free Hanging |
| Number of Pins | 20 |
| Number of Positions | 20 |
| Number of Rows | 2 |
| Orientation | Straight |
| Packaging | Bulk |
| Pitch | 2.54mm |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Row Spacing | 2.54mm |
| Termination | Crimp |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
