Connectors > Automotive Connectors

33472-1606 - Molex

Automotive Connector Housing, MX150 33472, Receptacle, 16 Ways

Technical Details

China RoHS	Compliant
Color	Black
Connector Type	Receptacle, Socket
Contact Gender	Female
Country of Origin	US
Current Rating	22A
Depth	36.95mm
Dielectric Material	Polystyrene
Export Control Classification Number (ECCN) Code	EAR99
Fastening Type	Latch
Gender	Receptacle
Housing Color	Black
Housing Material	Polyester
Harmonized Tariff Schedule (HTS) Code	8536.69.40.30
Introduction Date	2003-07-07
Lead Free	Lead Free
Length	39.65mm
Lifecycle Status	Production
Manufacturer Lifecycle Status	ACTIVE
Max Operating Temperature	125°C
Min Operating Temperature	-40°C
Mount	Free Hanging
Number of Contacts	16
Number of Pins	16
Number of Positions	16
Number of Rows	2
Orientation	Straight
Pitch	3.5052mm
Radiation Hardening	No
REACH SVHC	Yes
RoHS	Compliant
Termination	Crimp
Voltage Rating (DC)	250V

Compliance

RoHS : Unconfirmed

Radiation Hardening : No

REACH SVHC : Yes

Images

Molex 33472-1606 | Farnell

Farnell

Datasheets

Lifecycle Status Indicator

Production

Symbol

33472-1606 Symbol - Molex

33472-1606 Symbol - Molex

33472-1606 Symbol - Molex

33472-1606 Symbol - Molex

33472-1606 Symbol - Molex

33472-1606 Symbol - Molex

33472-1606 Symbol - Molex

33472-1606 Symbol - Molex

‹ ›

Footprint

33472-1606 Footprint - Molex

33472-1606 Footprint - Molex

33472-1606 Footprint - Molex

33472-1606 Footprint - Molex

‹ ›

Alternatives (Possible Substitutes)

Manufacturer	Manufacturer Part No.	Lifecycle Status Indicator	Confidence
Molex	33472-1601	Production
Molex	33472-1607	Production
Molex	33472-1602	Production
