39525-0003 - Molex
5.00mm Pitch Eurostyle Vertical PCB Header, with Threaded Retention Inserts, 3 Circuits
Technical Details
| China RoHS | Compliant |
| Color | Black |
| Contact Material | Brass |
| Contact Plating | Tin |
| Country of Origin | CN |
| Current | 15A |
| Current Rating | 15A |
| Depth | 8.3mm |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Housing Color | Black |
| Housing Material | Polyamide |
| Harmonized Tariff Schedule (HTS) Code | 8536.90.40.00 |
| Introduction Date | 2007-02-25 |
| Length | 25mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Operating Temperature | 105°C |
| Max Voltage Rating (AC) | 300V |
| Min Operating Temperature | -40°C |
| Mount | Through Hole |
| Number of Circuits | 2 |
| Number of Contacts | 3 |
| Number of Levels | 1 |
| Number of Positions | 3 |
| Number of Positions Per Level | 3 |
| Number of Rows | 1 |
| Orientation | Vertical |
| Packaging | Bulk |
| Pitch | 5mm |
| REACH SVHC | No |
| RoHS | Compliant |
| Termination | Solder |
| Voltage | 300V |
| Voltage Rating | 300V |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
