90131-0124 - Molex
2.54mm Pitch C-Grid III Header, Dual Row, Vertical, 8 Circuits, Tin (Sn) Plating
Technical Details
| Case/Package | 0124 |
| China RoHS | Compliant |
| Contact Gender | Male |
| Contact Material | Brass |
| Contact Plating | Tin |
| Contact Resistance | 20mΩ |
| Country of Origin | US |
| Current Rating | 3A |
| Dielectric Material | Polyester |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Gender | Male |
| Housing Color | Black |
| Housing Material | Polyester |
| Harmonized Tariff Schedule (HTS) Code | 8536.69.40.40 |
| Insulation Resistance | 5GΩ |
| Introduction Date | 1994-12-01 |
| Lead Free | Lead Free |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Mount | Through Hole |
| Number of Circuits | 8 |
| Number of Contacts | 8 |
| Number of Pins | 8 |
| Number of Positions | 8 |
| Number of Rows | 2 |
| Operating Force | 3.0024N |
| Orientation | Vertical |
| Pitch | 2.54mm |
| Plating | Tin |
| Plating Thickness | 4.064µm |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Row Spacing | 2.54mm |
| Schedule B | 8536694040, 8536694040|8536694040|8536694040|8536694040|8536694040 |
| Terminal Pitch | 2.54mm |
| Termination | Solder |
| Voltage Rating | 350V |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
