MCNDI-08S - Multicomp
Slide Dip Switch, 8 Switches, SPST, Latched, 0.025A, 24VDC, 16 PCB Hole Cnt, Solder Terminal, Through Hole-straight
Technical Details
| Contact Plating | Gold |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 2kcycles |
| Flammability Rating | UL94 V-0 |
| Harmonized Tariff Schedule (HTS) Code | 8536.50.90.65 |
| Insulation Resistance | 100MΩ |
| Introduction Date | 2014-08-05 |
| Lead Pitch | 2.54mm |
| Length | 21.26mm |
| Lifecycle Status | Production |
| Max Current Rating | 25mA |
| Max Operating Temperature | 70°C |
| Max Voltage Rating (DC) | 24V |
| Min Operating Temperature | -20°C |
| Number of Circuits | 8 |
| Number of Poles | 1 |
| Number of Positions | 8 |
| REACH SVHC | Unknown |
| RoHS | Compliant |
| Row Spacing | 7.62mm |
| Sealable | TOP TAPE SEALED |
| Throw Configuration | SPST |
Compliance
RoHS : Unconfirmed
REACH SVHC : Unknown
