LXES2SBBB4-026 - Murata
ESD protection diodes / TVS diodes; MURATA; LXES2SBBB4-026; 5.5 V; 6 V; 6 V; Surface Mount
Technical Details
| Breakdown Voltage | 7.5V |
| Capacitance | 1pF |
| Case/Package | SMD/SMT |
| Direction | Unidirectional |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 1.45mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2010-03-02 |
| Lead Free | Lead Free |
| Length | 2.9mm |
| Lifecycle Status | Obsolete |
| Max Breakdown Voltage | 9V |
| Max Operating Temperature | 85°C |
| Min Breakdown Voltage | 6V |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Bidirectional Channels | 4 |
| Number of Channels | 4 |
| Number of Elements | 1 |
| Number of Pins | 6 |
| Number of Terminals | 6 |
| Operating Supply Voltage | 5.5V |
| Packaging | Digi-Reel® |
| Polarity | Unidirectional |
| Power Line Protection | Yes |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Reverse Standoff Voltage | 5.5V |
| RoHS | Compliant |
| Termination | SMD/SMT |
| Voltage Rating | 6V |
| Voltage Rating (DC) | 6V |
| Working Voltage | 5.5V |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
Images
