Technical Details
| Ambient Temperature Range High | 105°C |
| Efficiency | 89.2% |
| Height | 5mm |
| Height - Seated (Max) | 5mm |
| Length | 10.5mm |
| Lifecycle Status | Production |
| Max Input Voltage | 15V |
| Max Junction Temperature (Tj) | 125°C |
| Max Operating Temperature | 105°C |
| Max Output Current | 24A |
| Max Output Power | 43.2W |
| Max Output Voltage | 1.8V |
| Max Supply Voltage | 15V |
| Min Input Voltage | 7.5V |
| Min Operating Temperature | -40°C |
| Min Output Voltage | 700mV |
| Min Supply Voltage | 7.5V |
| Nominal Input Voltage | 12V |
| Nominal Supply Current | 80mA |
| Number of Circuits | 1 |
| Number of Outputs | 1 |
| Number of Terminals | 56 |
| Output Current | 24A |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Schedule B | 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Switching Frequency | 400kHz |
| Topology | Buck |
| Width | 9mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
