PESD18VF1BLYL - Nexperia
PESD18VF Series 18 V 0.35 pF Bi-Directional SMT ESD Protection Diode - SOD-882
Technical Details
| Breakdown Voltage | 21.5V |
| Capacitance | 500fF |
| Case/Package | DFN |
| China RoHS | Compliant |
| Clamping Voltage | 17V |
| Composition | Zener |
| Contact Plating | Tin |
| Country of Origin | Mainland China |
| Depth | 620µm |
| Direction | Bidirectional |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Single |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2013-09-03 |
| Leakage Current | 30nA |
| Length | 1.02mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | RELEASED FOR SUPPLY |
| Max Breakdown Voltage | 24V |
| Max Operating Temperature | 150°C |
| Min Breakdown Voltage | 19V |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount, Through Hole |
| Number of Bidirectional Channels | 1 |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Peak Pulse Current | 1A |
| Peak Reverse Current | 30nA |
| Polarity | Bidirectional |
| Power Line Protection | No |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Reverse Standoff Voltage | 18V |
| RoHS | Compliant |
| Schedule B | 8536300000 |
| Working Voltage | 18V |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
