Technical Details
| Ambient Temperature Range High | 175°C |
| Continuous Drain Current (ID) | 4.8A |
| Drain to Source Breakdown Voltage | 40V |
| Drain to Source Resistance | 30mΩ |
| Drain to Source Voltage (Vdss) | 40V |
| Gate to Source Voltage (Vgs) | 20V |
| Height | 1.1mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | RELEASED FOR SUPPLY |
| Max Junction Temperature (Tj) | 175°C |
| Max Operating Temperature | 175°C |
| Max Power Dissipation | 1.3W |
| Min Breakdown Voltage | 40V |
| Min Operating Temperature | -55°C |
| Number of Channels | 1 |
| Number of Elements | 1 |
| Number of Terminals | 3 |
| Power Dissipation | 710mW |
| RoHS | Compliant |
| Turn-Off Delay Time | 20ns |
| Turn-On Delay Time | 4ns |
Compliance
RoHS : Unconfirmed
