PRTR5V0U2AX,215 - Nexperia
PRTR Series 9 V 1.8 pF Rail-to-Rail ESD Protection Diode - SOT-143B
Technical Details
| Ambient Temperature Range High | 125°C |
| Breakdown Voltage | 7.5V |
| Capacitance | 1.8pF |
| China RoHS | Compliant |
| Contact Plating | Tin |
| Country of Origin | Mainland China |
| Direction | Unidirectional |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 1.1mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2006-12-22 |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | RELEASED FOR SUPPLY |
| Max Breakdown Voltage | 9V |
| Max Operating Temperature | 85°C |
| Min Breakdown Voltage | 6V |
| Min Operating Temperature | -40°C |
| Number of Channels | 2 |
| Number of Elements | 1 |
| Number of Pins | 4 |
| Number of Terminals | 4 |
| Operating Supply Voltage | 700mV |
| Peak Reverse Current | 100nA |
| Polarity | Unidirectional |
| REACH SVHC | Yes |
| Reverse Standoff Voltage | 3V |
| RoHS | Compliant |
| Schedule B | 8541100080, 8541100080|8541100080|8541100080|8541100080|8541100080 |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
