PRTR5V0U2F,115 - Nexperia
6V Unidirectional 5.5V XSON-6(1x1.5) ESD and Surge Protection (TVS/ESD) ROHS
Technical Details
| Ambient Temperature Range High | 85°C |
| Breakdown Voltage | 7.5V |
| Capacitance | 1pF |
| Case/Package | SOT-886 |
| China RoHS | Compliant |
| Contact Plating | Tin |
| Country of Origin | Mainland China, Malaysia |
| Depth | 1.05mm |
| Direction | Unidirectional |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Dual |
| Height | 500µm |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2008-11-07 |
| Lead Free | Lead Free |
| Leakage Current | 100nA |
| Length | 1.5mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | RELEASED FOR SUPPLY |
| Max Breakdown Voltage | 9V |
| Max Operating Temperature | 85°C |
| Min Breakdown Voltage | 6V |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Bidirectional Channels | 2 |
| Number of Channels | 2 |
| Number of Elements | 1 |
| Number of Pins | 6 |
| Number of Terminals | 6 |
| Peak Reverse Current | 10nA |
| Polarity | Unidirectional |
| Power Line Protection | Yes |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Reverse Breakdown Voltage | 6V |
| Reverse Standoff Voltage | 5.5V |
| RoHS | Compliant |
| Schedule B | 8536300000 |
| Working Voltage | 5.5V |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
