MB2061SB3W01-BA - NKK Switches
Pushbutton Switch, DPDT, On-(on), Momentary, Solder Terminal, Panel Mount
Technical Details
| Actuator Length | 11.7856mm |
| Color | Black |
| Contact Current Rating | 3A |
| Contact Material | Silver |
| Contact Plating | Silver |
| Contact Resistance | 10mΩ |
| Contact Voltage Rating (AC) | 250V |
| Current Rating | 3A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 25kcycles |
| Flammability Rating | UL94 V-0 |
| Height | 40.767mm |
| Housing Material | Stainless Steel |
| Harmonized Tariff Schedule (HTS) Code | 8536.50.70.00 |
| Insulation Resistance | 1GΩ |
| Introduction Date | 1999-01-01 |
| Length | 13.0048mm |
| Lifecycle Status | Obsolete |
| Max Operating Temperature | 85°C |
| Mechanical Life | 50kcycles |
| Min Operating Temperature | -15°C |
| Mount | Panel |
| Packaging | Bulk |
| Ratings | Dust Tight, IP67, Waterproof |
| REACH SVHC | No |
| RoHS | Compliant |
| Sealable | EPOXY |
| Switch Function | On-Mom |
| Termination | Solder |
| Throw Configuration | DPDT |
| Voltage Rating (AC) | 125V |
| Voltage Rating (DC) | 30V |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
Images
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| NKK Switches | Obsolete | ||
| NKK Switches | Obsolete | ||
| NKK Switches | Obsolete | ||
| NKK Switches | Obsolete | ||
| NKK Switches | Obsolete | ||
| NKK Switches | Obsolete | ||
| NKK Switches | Obsolete | ||
| NKK Switches | Obsolete | ||
| NKK Switches | Unknown | ||
| NKK Switches | Obsolete |
