NTE5014A - NTE Electronics
Diode, Zener, Vr 6.8V, If 200MA, Pkg DO-35, Vf 1.1V, Tj +200DEGC, Pd 500MW, Ir 20MA
Technical Details
| Breakdown Voltage | 1.1V |
| Diameter | 2.28mm |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Single |
| Height | 12.7mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Impedance | 5Ω |
| Introduction Date | 1992-06-01 |
| Length | 5.08mm |
| Lifecycle Status | Obsolete |
| Max Operating Temperature | 200°C |
| Max Power Dissipation | 500mW |
| Max Reverse Leakage Current | 3µA |
| Min Operating Temperature | -65°C |
| Mount | Through Hole |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Polarity | Unidirectional |
| Power Dissipation | 500mW |
| Reference Voltage | 6.8V |
| RoHS | Compliant |
| Termination | Axial |
| Test Current | 20mA |
| Voltage Tolerance | 5% |
| Weight | 72.574779g |
| Width | 76.2mm |
| Zener Current | 20mA |
| Zener Voltage | 6.8V |
Compliance
RoHS : Unconfirmed
Images
