PCA9633DP1,118 - NXP Semiconductors
PCA9633 Series 25 mA 5.5 V 1 MHz SMT 8-bit I2C-Bus LED Driver - TSSOP-8
Technical Details
| Case/Package | TSSOP |
| China RoHS | Compliant |
| Frequency | 25MHz |
| Height | 950µm |
| Height - Seated (Max) | 1.1mm |
| High Level Output Current | 50µA |
| Lead Free | Lead Free |
| Length | 3mm |
| Lifecycle Status | Production |
| Low Level Output Current | 100mA |
| Max Operating Temperature | 85°C |
| Max Power Dissipation | 400mW |
| Max Supply Current | 10mA |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.3V |
| Nominal Supply Current | 10mA |
| Number of Bits | 4 |
| Number of Characters | 4 |
| Number of Circuits | 1 |
| Number of Outputs | 4 |
| Number of Pins | 8 |
| Number of Segments | 8 |
| Number of Terminals | 8 |
| Operating Supply Voltage | 3.3V |
| Output Current | 25mA |
| Output Current per Channel | 25mA |
| Output Voltage | 5.5V |
| Power Dissipation | 400mW |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Temperature Grade | Industrial |
| Terminal Pitch | 650µm |
| Width | 3mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
Images
Future Electronics
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| NXP Semiconductors | Production | ||
| NXP Semiconductors | Production | ||
| NXP Semiconductors | EOL | ||
| NXP Semiconductors | Obsolete | ||
| NXP Semiconductors | Obsolete | ||
| NXP Semiconductors | Obsolete | ||
| NXP Semiconductors | Obsolete | ||
| NXP Semiconductors | Obsolete | ||
| onsemi | Obsolete | ||
| onsemi | Obsolete |
