A6S-7102-PH - Omron
Switch DIP OFF ON SPST 7 Recessed Slide 0.025A 24VDC Gull Wing 1000Cycles 2.54mm SMD T/R
Technical Details
| Actuator Length | 0m |
| Ambient Temperature Range High | 70°C |
| Case/Package | DIP |
| Contact Current Rating | 25mA |
| Contact Plating | Gold |
| Contact Resistance | 200mΩ |
| Country of Origin | Vietnam |
| Current Rating | 25mA |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 1kcycles |
| Height | 3mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.50.90.65 |
| Insulation Resistance | 100MΩ |
| Introduction Date | 2007-03-07 |
| Length | 18.72mm |
| Life (Cycles) | 1kcycles |
| Lifecycle Status | Production |
| Max Current Rating | 25mA |
| Max Operating Temperature | 70°C |
| Max Voltage Rating (DC) | 24V |
| Mechanical Life | 1kcycles |
| Min Operating Temperature | -20°C |
| Mount | Surface Mount |
| Number of Circuits | 7 |
| Orientation | Straight |
| Pitch | 2.54mm |
| RoHS | Compliant |
| Sealable | IP40, WATER PROOF, TOP TAPE SEALED |
| Terminal Pitch | 2.54mm |
| Termination | Gull Wing |
| Throw Configuration | SPST |
| Voltage Rating (DC) | 24V |
| Washable | Yes |
Compliance
RoHS : Unconfirmed
