B3U-3000PM - Omron
Switch Tactile N.O. SPST Button Gull Wing 0.05A 12VDC 1.59N SMD Embossed T/R
Technical Details
| Actuator Length | 700µm |
| Ambient Temperature Range High | 70°C |
| Case/Package | SMD/SMT |
| Color | Black |
| Connector Type | SMD/SMT |
| Contact Current Rating | 50mA |
| Contact Material | Silver |
| Contact Resistance | 100mΩ |
| Current Rating | 50mA |
| Depth | 3.2mm |
| Electrical Life | 100kcycles |
| Height | 1.2mm |
| Illumination Type | Illuminated, Non-Illuminated |
| Insulation Resistance | 100MΩ |
| Length | 4mm |
| Life (Cycles) | 100kcycles |
| Lifecycle Status | Production |
| Max Current Rating | 50mA |
| Max Operating Temperature | 70°C |
| Max Voltage Rating (DC) | 12V |
| Mechanical Life | 100kcycles |
| Min Operating Temperature | -25°C |
| Mount | Surface Mount |
| Number of Positions | 1 |
| Operating Force | 1.59N |
| Orientation | Right Angle |
| Ratings | Dust Proof |
| REACH SVHC | Unknown |
| RoHS | Compliant |
| Schedule B | 8536509065, 8536509065|8536509065|8536509065|8536509065|8536509065 |
| Sealable | IP40 |
| Switch Function | Off-Mom |
| Switch Travel | 200µm |
| Termination | Gull Wing |
| Throw Configuration | SPST |
| Voltage Rating (DC) | 12V |
| Weight | 22mg |
Compliance
RoHS : Unconfirmed
REACH SVHC : Unknown
