Technical Details
| Average Rectified Current | 3A |
| Breakdown Voltage | 1kV |
| China RoHS | Non-Compliant |
| Current Rating | 3A |
| Element Configuration | Single |
| Forward Current | 3A |
| Forward Voltage | 1V |
| Lifecycle Status | Obsolete |
| Manufacturer Lifecycle Status | OBSOLETE |
| Max Forward Surge Current (Ifsm) | 200A |
| Max Operating Temperature | 150°C |
| Max Output Current | 3A |
| Max Repetitive Reverse Voltage (Vrrm) | 1kV |
| Max Reverse Voltage (DC) | 1kV |
| Max Surge Current | 200A |
| Min Operating Temperature | -65°C |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Output Current | 3A |
| Packaging | Tape and Reel |
| Peak Reverse Current | 10µA |
| Polarity | Standard |
| REACH SVHC | No |
| Reverse Standoff Voltage | 1kV |
| Reverse Voltage | 1kV |
| RoHS | Compliant |
| Voltage Rating (DC) | 1kV |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
