Technical Details
| Breakdown Voltage | 18.75V |
| China RoHS | Non-Compliant |
| Clamping Voltage | 26V |
| Composition | Zener |
| Country of Origin | Malaysia |
| Direction | Unidirectional |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Forward Voltage | 1.25V |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2001-01-01 |
| Lead Free | Contains Lead |
| Lifecycle Status | Obsolete |
| Max Breakdown Voltage | 19.7V |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 500mW |
| Max Surge Current | 7.7A |
| Min Breakdown Voltage | 17.8V |
| Min Operating Temperature | -55°C |
| Number of Channels | 1 |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Number of Unidirectional Channels | 1 |
| Operating Supply Voltage | 16V |
| Packaging | Tape and Reel |
| Peak Pulse Power | 200W |
| Peak Reverse Current | 1µA |
| Polarity | Unidirectional |
| Power Line Protection | No |
| REACH SVHC | No |
| Reference Voltage | 16V |
| Reverse Standoff Voltage | 16V |
| RoHS | Compliant |
| Termination | SMD/SMT |
| Voltage Tolerance | 5% |
| Zener Current | 1mA |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
