1PMT5927BT1G - onsemi
Zener Diode Single 12V 5% 6.5Ohm 3200mW 2-Pin(1+Tab) Power Mite T/R
Technical Details
| China RoHS | Non-Compliant |
| Country of Origin | Malaysia |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Single |
| Halogen Free | Halogen Free |
| Height | 1.15mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Impedance | 6.5Ω |
| Introduction Date | 2001-01-01 |
| Lead Free | Lead Free |
| Length | 2.18mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Material | Plastic |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 500mW |
| Max Reverse Leakage Current | 1µA |
| Min Operating Temperature | -55°C |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Terminals | 1 |
| Packaging | Tape and Reel |
| Peak Reverse Current | 1µA |
| Polarity | Unidirectional |
| Power Dissipation | 500mW |
| Power Rating | 3.2W |
| Radiation Hardening | No |
| REACH SVHC | No |
| Reference Voltage | 12V |
| Reverse Standoff Voltage | 9.1V |
| RoHS | Compliant |
| Schedule B | 8541100050, 8541100050|8541100050|8541100050|8541100050|8541100050 |
| Test Current | 31.2mA |
| Tolerance | 5% |
| Voltage Rating (DC) | 12V |
| Voltage Tolerance | 5% |
| Width | 2.05mm |
| Zener Current | 31.2mA |
| Zener Voltage | 12V |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
