1SMB5944BT3 - onsemi
Tape & Reel (TR) ±5% Surface Mount ZENER DIODE Zener Diode 1.5V @ 200mA 1muA @ 47.1V 550mW 62V
Technical Details
| Case/Package | SMB |
| China RoHS | Non-Compliant |
| Country of Origin | Malaysia |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Single |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Impedance | 100Ω |
| Introduction Date | 1994-05-01 |
| Lead Free | Contains Lead |
| Lifecycle Status | Obsolete |
| Manufacturer Lifecycle Status | OBSOLETE |
| Max Operating Temperature | 175°C |
| Max Power Dissipation | 550mW |
| Max Reverse Leakage Current | 1µA |
| Min Operating Temperature | -65°C |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Packaging | Tape and Reel |
| Polarity | Unidirectional |
| Power Dissipation | 550mW |
| Power Rating | 3W |
| REACH SVHC | No |
| Reference Voltage | 62V |
| RoHS | Compliant |
| Tolerance | 5% |
| Voltage Rating (DC) | 62V |
| Voltage Tolerance | 5% |
| Zener Current | 6mA |
| Zener Voltage | 62V |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
