2SD1815T-E - onsemi
Bulk Through Hole NPN Single Bipolar (BJT) Transistor 70 @ 500mA 5V 3A 1W 130MHz
Technical Details
| Case/Package | TO-251-3 |
| Collector Base Voltage (VCBO) | 120V |
| Collector Emitter Breakdown Voltage | 100V |
| Collector Emitter Saturation Voltage | 150mV |
| Collector Emitter Voltage (VCEO) | 100V |
| Contact Plating | Tin Bismuth |
| Country of Origin | Mainland China |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Single |
| Emitter Base Voltage (VEBO) | 6V |
| Frequency | 130MHz |
| Gain Bandwidth Product | 180MHz |
| hFE Min | 200 |
| Introduction Date | 2012-05-02 |
| Lead Free | Lead Free |
| Lifecycle Status | EOL |
| Manufacturer Lifecycle Status | LAST SHIPMENTS |
| Max Collector Current | 3A |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 20W |
| Min Operating Temperature | -55°C |
| Number of Elements | 1 |
| Number of Pins | 3 |
| Packaging | Bulk |
| Polarity | NPN |
| Power Dissipation | 1W |
| REACH SVHC | No |
| RoHS | Compliant |
| Transition Frequency | 180MHz |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
Images
