2SK3738-TL-E - onsemi
2SK3738-TL-E N-channel Jfet Transistor, 40 V, Idss 0.05 to 0.13MA, 3-PIN SOT-23
Technical Details
| Case/Package | SOT-23 |
| Contact Plating | Tin Bismuth |
| Continuous Drain Current (ID) | 1mA |
| Country of Origin | Mainland China |
| Drain to Source Resistance | 200Ω |
| Drain to Source Voltage (Vdss) | 40V |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Single |
| Gate to Source Voltage (Vgs) | -20V |
| Height | 1.1mm |
| Input Capacitance | 1.7pF |
| Introduction Date | 2012-09-11 |
| Lead Free | Lead Free |
| Length | 2.9mm |
| Lifecycle Status | Obsolete |
| Manufacturer Lifecycle Status | OBSOLETE |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 100mW |
| Min Operating Temperature | -55°C |
| Number of Pins | 8 |
| Packaging | Tape and Reel |
| Power Dissipation | 100mW |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Width | 1.5mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
Images
Rochester Electronics
Authorized Distributors
| Distributor | SKU | Stock | USD | 1 | 10 | 50 | 100 | 1000 | 10000 | Buy |
|---|---|---|---|---|---|---|---|---|---|---|
| Rochester Electronics |
US: 27603
|
$ | 0.1718 | 0.1426 | 0.1271 | |||||
| Verical |
US: 26752
|
$ | 0.1589 | |||||||
