55GN01CA-TB-E - onsemi
55GN01CA Series NPN 10 V 200 mW 70 mA UHF Wide-Band Low Noise Amplifier - CP-3
Technical Details
| Case/Package | TO-236-3 |
| China RoHS | Compliant |
| Collector Base Voltage (VCBO) | 20V |
| Collector Emitter Breakdown Voltage | 10V |
| Collector Emitter Voltage (VCEO) | 10V |
| Contact Plating | Tin Bismuth |
| Continuous Collector Current | 5mA |
| Country of Origin | Mainland China |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Single |
| Emitter Base Voltage (VEBO) | 3V |
| Frequency | 5.5GHz |
| Gain | 9.5dB |
| Gain Bandwidth Product | 4.5GHz |
| Height | 1.1mm |
| hFE Min | 100 |
| Introduction Date | 2011-06-24 |
| Lead Free | Lead Free |
| Length | 2.9mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Breakdown Voltage | 10V |
| Max Collector Current | 70mA |
| Max Frequency | 5.5GHz |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 200mW |
| Min Operating Temperature | 25°C |
| Number of Elements | 1 |
| Number of Pins | 3 |
| Number of Terminals | 3 |
| Packaging | Tape and Reel |
| Polarity | NPN |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Transition Frequency | 5.5GHz |
| Width | 1.5mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
Images
Rochester Electronics
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| onsemi | Obsolete | ||
| Fairchild Semiconductor | Obsolete | ||
| onsemi | Obsolete | ||
| onsemi | Obsolete | ||
| onsemi | Obsolete | ||
| onsemi | Unknown | ||
| Fairchild Semiconductor | Obsolete | ||
| Fairchild Semiconductor | Obsolete | ||
| onsemi | Obsolete | ||
| onsemi | Obsolete |
