BC857BWT1 - onsemi
Tape & Reel (TR) Surface Mount PNP Single Bipolar (BJT) Transistor 220 @ 2mA 5V 100mA 150mW 100MHz
Technical Details
| China RoHS | Non-Compliant |
| Collector Base Voltage (VCBO) | -50V |
| Collector Emitter Breakdown Voltage | 45V |
| Collector Emitter Saturation Voltage | -650mV |
| Collector Emitter Voltage (VCEO) | 45V |
| Country of Origin | Mainland China |
| Current Rating | -100mA |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Single |
| Emitter Base Voltage (VEBO) | 5V |
| Gain Bandwidth Product | 100MHz |
| hFE Min | 220 |
| Introduction Date | 1996-04-01 |
| Lead Free | Contains Lead |
| Lifecycle Status | Obsolete |
| Manufacturer Lifecycle Status | OBSOLETE |
| Max Collector Current | 100mA |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 150mW |
| Min Operating Temperature | -55°C |
| Number of Elements | 1 |
| Number of Pins | 3 |
| Number of Terminals | 3 |
| Packaging | Tape and Reel |
| Polarity | PNP |
| REACH SVHC | No |
| RoHS | Compliant |
| Transition Frequency | 100MHz |
| Voltage Rating (DC) | -45V |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
Images
Rochester Electronics
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Diodes Inc. | Production | ||
| STMicroelectronics | Obsolete | ||
| Diotec | Production | ||
| onsemi | Production | ||
| Diodes Inc. | Obsolete | ||
| Infineon | Obsolete | ||
| Nexperia | Production | ||
| Nexperia | Production | ||
| MCC | Production | ||
| Central Semiconductor | Production |
